Three-Way Adjustable Concealed Cabinet Hinge - Multiple Finishes Available - Sold Individually

Sugatsune

$ 0.00
SKU: SUG-HES3D-70DC

888-250-8133
  • Free shipping on orders over $50
  • Easy 30 day returns
  • Typically ships in 1-2 business days

 Product Specifications:

  • 3-Way Adjustable Concealed Cabinet Hinge
  • Install concealed hinges on the inside of your cabinets to create sleek lines on both the exterior and interior
  • Also called Invisible Hinges
  • Materials: Zinc Alloy, Stainless Steel, ABS
  • Finishes Available: Dull Chrome, Dull Nickel, Matte Black
  • Consist of 2 piece assembly: one that connects to the door, and one inside the cabinet wall
  • 3-Way adjustment function allows vertical, horizontal and depth adjustment after installation
  • Hinge leaves separate for easy installation
  • Great for double-door frameless cabinets
  • Covers hide screw heads for clean appearance
  • Small size for min. 3/4" panel thickness
  • Maximum Door Weight: 19.8 lbs (9 kg) per 2 pcs, 26.4 lbs (12 kg) per 3 pcs
  • Minimum Door Thickness: 3/4" Inch (19 mm)
  • Maximum Door Size: H 47-1/4" Inches × W 23-5/8" Inches (1200 mm x 600 mm)
  • Steel countersunk wood screws included
  • Sold Individually
