Locinox Mangus Motorized Hinge & Gate Closer in One for Pedestrian Gates

The Locinox MAGNUS Motorized Hinge & Gate Closer is an innovative all-in-one motorized hinge and gate closer designed to automate pedestrian swing gates while maintaining ADA-compliant operation. Combining the hinge, motor, and closing mechanism into a single compact unit, MAGNUS delivers smooth, reliable gate automation without bulky arms or external operators.

Powered by a durable brushless 24V DC motor, MAGNUS provides quiet, energy-efficient operation and adapts automatically to pedestrian traffic. Its low-energy mode ensures safe and accessible gate movement while meeting accessibility requirements for public and commercial environments.

With integrated electronics and app-based configuration, installers can easily adjust speed, force, and access control settings. Built with a robust steel gearbox and anodized aluminum housing, the system is engineered for long-term reliability in demanding outdoor installations.

Magnus is easy to install with quick fix bolts. The fully integrated motor and control system make for a true plug-in play installation. Once wired, an intuitive app guides you through the setup

Ideal for schools, commercial properties, apartment complexes, and public access gates, MAGNUS offers a sleek, vandal-resistant solution for automated pedestrian entry.

Key Features

• All-in-one design: Motorized hinge and gate closer combined into one compact unit

• ADA-compliant operation: Low-energy motor for accessible pedestrian gates

• Brushless motor technology: Quiet operation with extended lifespan

• Smart configuration: Setup and adjust settings via intuitive mobile app

• Obstacle detection: Automatic reverse function for enhanced safety

• Heavy-duty construction: Steel gearbox with anodized aluminum housing

• Quick-Fix installation: Fast mounting with Locinox Quick-Fix bolts

• Manual operation capability: Back-drivable motor allows easy manual opening

Technical Specifications

• Maximum torque: 100 Nm

• Power supply: 110–240V AC input

• Motor voltage: 24V DC

• Gate capacity: Up to 440 lbs (200 kg)

• Maximum gate width: Up to 5 ft (1500 mm)

• Maximum opening angle: 180°

• IP rating: IP56 weather resistance

• Connection box: 3 inputs / 3 outputs (24V DC, max. 48W)

• Compliance: UL / cUL 325 and EN 16005 standards

• Tested durability: Up to 500,000 cycles

Applications

Perfect for:

• Pedestrian security gates

• Commercial and industrial properties

• Residential communities and HOAs

• Schools and universities

• Public access facilities requiring ADA compliance

Automate your pedestrian gate with a single integrated hinge solution.
The Locinox MAGNUS delivers safe, quiet, and reliable gate automation without bulky operators or complicated installations.
